N35 N42 N52 Disc Neodymium Permanent Magnets Nickel Coating For Speaker

    Buy cheap N35 N42 N52 Disc Neodymium Permanent Magnets Nickel Coating For Speaker from wholesalers

    Buy cheap N35 N42 N52 Disc Neodymium Permanent Magnets Nickel Coating For Speaker from wholesalers
    • Buy cheap N35 N42 N52 Disc Neodymium Permanent Magnets Nickel Coating For Speaker from wholesalers
    • Buy cheap N35 N42 N52 Disc Neodymium Permanent Magnets Nickel Coating For Speaker from wholesalers

    N35 N42 N52 Disc Neodymium Permanent Magnets Nickel Coating For Speaker

    Ask Lasest Price
    Brand Name : YuXiang
    Model Number : N35-N52 Disc Neodymium Magnet
    Certification : SGS, ISO9001, RoHS
    Price : Negotiated
    Supply Ability : 800Ton/year
    Delivery Time : 15~30 Days After Confirmed Order
    • Product Details
    • Company Profile

    N35 N42 N52 Disc Neodymium Permanent Magnets Nickel Coating For Speaker

    N35 N42 N52 Disc NdFeB Magnet For Speaker Round D20mm, D10mm, D15mm*2mm

    Very strong disc magnet. Given its holding power of 64 kg, one must naturally take extra care when handling these. With a diameter of 4, 5 cm, this magnet hardly looks suspicious. Ah, but looks can be deceiving! Once in contact with a thick piece of metal, this magnet is nearly impossible to remove again. Paperclips and nails - even at a 8 cm distance - cannot withstand the pull!

    GradeMax. Energy ProductRemanenceCoercive ForceRev. Temp. Coeff.Curie Temp.Working Temp.
    (BH)maxBrHcHciBdHdTcTw
    MGOekJ/m3kGmTkOekA/mkOekA/m%/oC%/oCoCoC
    N3533-36263-28711.70-12.101170-1210>10.9>868>12>955-0.12-0.631080
    N3836-39287-31012.10-12.501210-1250>11.3>899>12>955-0.12-0.631080
    N4038-41302-32612.50-12.801250-1280>11.6>923>12>955-0.12-0.631080
    N4240-43318-34212.80-13201280-1320>11.6>923>12>955-0.12-0.631080
    N4543-46342-36613.20-13.801320-1380>11.0>876>12>955-0.12-0.631080
    N4846-49366-39013.80-14.201380-1420>10.5>835>11>876-0.12-0.631080
    N5047-51347-40613.9-14.31390-1430>10.5>836>11>876-0.12-0.631080
    N30M28-32223-25510.90-11.701090-1170>10.2>812>14>1114-0.12-0.59320100
    N33M31-35247-27911.40-12.201140-1220>10.7>851>14>1114-0.12-0.59320100
    N35M33-37263-29411.80-12.501180-1250>11.0>875>14>1114-0.12-0.59320100
    N38M36-40286-31812.30-13.001230-1300>11.5>915>14>1114-0.12-0.59320100
    N40M38-42302-33412.60-13.201260-1320>11.8>939>14>1114-0.12-0.59320100
    N42M40-44318-35013.00-13.501300-1350>12.0>955>14>1114-0.12-0.59320100
    N45M42-46334-36613.20-13.801320-1380>12.2>971>14>1114-0.12-0.59320100
    N33H31-34247-27111.30-11.701130-1170>10.5>836>17>1353-0.11-0.58320-350120
    N35H33-36263-28711.70-12.101170-1210>10.9>868>17>1353-0.11-0.58320-350120
    N38H36-39287-31012.10-12.501210-1250>11.3>899>17>1353-0.11-0.58320-350120
    N40H38-41302-32612.40-12.801240-1280>11.6>923>17>1353-0.11-0.58320-350120
    N42H40-43318-34212.80-13.201280-1320>12.0>955>17>1360-0.11-0.58320-350120
    N33SH31-34247-27211.30-11.701130-1170>10.6>844>20>1592-0.11-0.55340-360150
    N35SH33-36263-28711.70-12.101170-1210>11.0>876>20>1592-0.11-0.55340-360150
    N38SH36-39287-31012.10-12.501210-1250>11.4>907>20>1592-0.11-0.55340-360150
    N40SH38-41302-32612.10-12.801240-1280>11.8>939>20>1592-0.11-0.55340-360150
    N28UH26-29207-23110.20-10.801020-1080>9.6>768>25>1990-0.11-0.51350-380180
    N30UH28-31223-24710.80-11.301080-1130>10.2>816>25>1990-0.11-0.51350-380180
    N33UH31-34247-27111.30-11.701130-1170>10.7>856>25>1990-0.11-0.51350-380180
    N28EH26-29211-23610.40-10.901040-1090>9.8>784>30>2388-0.11-0.51350-380200


    Features:
    1. Neodymium Disc Permanent Magnes many different grades of: N35, N38, N40, N42, N45, N48, N50, N52(M, H, SH, UH, EH) etc.
    2. Working temperature for Neodymium disc magnets: From 80 centigrades to 200 centigrades.
    3. Can be magnetized according to the requirements of clients, thickness, diameter, muti-poles
    4. Coatings: Ni, Zn, epoxy, gold, silver, Cu and so on(as per the requirements)
    5. Neodymium magnet has super strong magnetic force and high intrinsic coercive force
    6. With precise tolerance...

    Applications
    Loudspeakers, motor assemblies, windmill, Home appliance, acousics, communication equipment, toy, car, servomotor, step motor, DC motor and linear motor, mircrophones.

    For more detail info, please feel free to visit our website or inquire us at any of your convenience.
